mHPC200

產品階段 : 供應中

2U Rackmount Server with Dual Intel® Xeon® Gold 6226R Processors, Intel® C621 PCH for HPC in Medical Applications

產品特色

CPU	Dual LGA3647 server-grade Intel® Xeon® Gold 6226R processors 2.9GHz, 22MB Cache 16 cores
Chipset	PCH: Intel® C621, TDP 15W BMC: ASpeed AST2500A2-GP Embedded Graphics SoC: SiliconMotion SM768
System Memory	12 x DDR4-2933 ECC RDIMM, up to 384GB
Graphics	Single HDMI 1.4 supported by SM768
BIOS	AMI version V1.04
Remote Management	IPMI 2.0 compliant
COM	N/A
USB	4 x USB 3.0
Ethernet	1 x LAN (BMC/IPMI) 1 x Network card supports dual 10G Base-T & dual SFP+
Display	1 x HDMI FHD
Storage	2 x 2.5" hot-swappable SATA SSD slot, in upport of 2 x 256G SSD (RAID 1) 2 x 2.5" hot-swappable U.2 SSD slot in support of 1 x 6.4T U.2 SSD (RAID 0)
Expansion	2 PCIe riser cards inside: 2 x PCIe x16 Gen 3.0 slots 1 x PCIe x16 slot, 1x PCIe x8 slot, M.2 22110-M slot
Others	2 x 110 to 240 VAC power input 2 x LED status (power-on, SSD act.)
Power Supply	2 x 1200W redundant ATX power supply
Watchdog Timer	Reset: 1 - 65535 sec./min. and 1 sec. or 1 min./step
Operating Temperature	0°C to +40°C (32°F to +104°F)
Relative Humidity	10% - 95%, non-condensing
Vibration Endurance	Heavy-duty steel
Dimensions (W x D x H)	430 x 600 x 88 mm (19” x 19.4” x 3.5”)
Weight (net/gross)	11.9 kg (26 lb) /16.10 kg (35 lb)
EOS Support	CentOS 7.6 & Windows 10 IoT
Certifications	CE, IEC 62368-1, FCC Class A compliant

mHPC200-CCL
2U 19" rackmount server with dual Intel® Xeon® Gold 6226R processors, 384GB DDR4-2933 ECC registered DIMM memory, single Micron 6.4TB PCIe NVMe U.2 SSD, two 256GB SATA III SSD, single network card
RAM (P/N-E9C1816K00)
32GB ECC RDIMM DDR4-2933 288PIN Micron (MTA36ASF4G72PZ-2G9E2), 64GB to 384GB
U.2 SSD (P/N-E9B2Q00060)
Micron 9300 max series 6.4TB NVMe U.2 SSD (MTFDHAL6T4TDR-1AT1ZABYY) QTY
SATAIII SSD (P/N-E9B2F1256R)
Transcend 2.5“ 256GB SATAIII SSD (TS256S2MAX02IK1) QTY
22" Rack rail (P/N-7421A610000E)
NJ-21A61 SERVER SLIDE 22”
