It is powered by the Intel® Celeron® J6412 processor (Elkhart Lake), delivering energy-efficient performance for IoT and embedded applications.
The motherboard features two DDR4 SO-DIMM slots and supports up to 32GB of system memory.
Its low-profile Thin Mini-ITX design reduces board height compared to standard Mini-ITX, making it ideal for compact installations.
Yes, it includes an M.2 Key B slot and SIM card slot, allowing integration of 5G modules for high-speed wireless communication.
The MANO321 supports triple display via HDMI, VGA, and LVDS, making it suitable for multi-screen applications.
It supports SATA storage, mSATA, SD card (SDHX), and M.2 Key B (also compatible with SATA SSD), offering flexible storage configurations.
It includes one PCIe x4 slot (with PCIe x2 signal) and one PCI Express Mini Card slot for additional modules and customization.
The MANO321 offers rich I/O, including six COM ports, USB 3.1 and USB 2.0 ports, dual Gigabit LAN, DIO, HDMI, VGA, LVDS, and SMBus.
Yes, it is designed with industrial-grade features, including reliable connectivity, multiple I/O options, and robust performance for IoT deployment.
Yes, it supports TPM 2.0 and includes a watchdog timer for enhanced system security and reliability.
The MANO321 supports both Windows and Linux operating systems.
It is ideal for industrial automation, IoT gateways, digital signage, smart transportation systems, and other edge computing applications.
