It supports dual 3rd Gen Intel® Xeon® Scalable processors (Ice Lake-SP) through dual LGA4189 sockets, providing enterprise-class computing performance.
Depending on the processor configuration, the platform supports up to 38 cores per CPU, enabling efficient handling of intensive AI and HPC workloads.
The motherboard features six DDR4-3200 RDIMM slots and supports up to 384GB of server-grade memory.
Yes, it supports GPU expansion and benefits from Intel® AI acceleration technologies built into the 3rd Gen Xeon® platform.
The IMB700 offers three PCIe x16 slots, three PCIe x8 slots, and an M.2 Key M 2280 interface, allowing integration of GPUs, capture cards, RAID controllers, and other high-performance add-on cards.
It includes six SATA-600 ports with RAID 0, 1, 5, and 10 support, as well as an M.2 NVMe slot for high-speed storage.
RAID functionality helps protect stored data, while TPM 2.0 provides hardware-based security for critical information.
It offers USB 3.1 Gen1, USB 2.0, dual Gigabit Ethernet ports, serial communication, VGA, programmable DIO, HD audio, SMBus, and PS/2 interfaces for broad industrial compatibility.
Yes, it supports an operating temperature range from 0°C to +60°C and includes hardware monitoring and watchdog timer functions for enhanced reliability.
Its dual Xeon® architecture, large memory capacity, extensive PCIe expansion, high-speed storage support, and server-grade reliability make it an ideal platform for demanding AI and compute-intensive applications.
