| CPU |
- Intel® Core™ Processors Series 2 & 14th/13th/12th Gen Intel® Core™ processor, up to 65W
|
| Chipset |
|
| System Memory |
- 2 x 262-pin DDR5 4800/4000 non-ECC SO-DIMM, up to 96GB
|
| BIOS |
|
| COM |
- 1 x RS-232 (4-wire)/RS-422/485 (default: RS-232, M12 A-coded)
|
| USB |
- 4 x USB 3.2 Gen1 (5G) Type-A
- 2 x USB 2.0 (M12 A-coded)
- 1 x USB 2.0 (internal, up to 30 mm) 180D Type-A
|
| Ethernet |
- 2 x 2.5GbE LAN (Intel® I226-V, M12 X-coded)
- 1 x GbE LAN (Intel® I219-LM, M12 X-coded)
|
| Display |
- 1 x HDMI 1.4b with 4096 x 2160 resolution supported
|
| Digital I/O |
|
| Audio |
|
| Storage |
- 1 x SSD/HDD drive bay (7/9.5/15 mm height)
- 1 x SSD/HDD drive bay (optional, 7/9.5/15 mm height, project-base support)
- 1 x M.2 Key M 2280 socket (PCIe x4 Gen 3)
|
| Expansion |
- 1 x full-size PCI Express Mini Card slot (USB & PCIe interface) with SIM slot
- 2 x blank I/O openings are reserved for expansion
|
| Others |
- dTPM2.0
- 3 x antenna openings
|
| Power |
- Input: 18 to 36 VDC
- ACC ignition
- 1 x DC power connector (M12, A-coded)
- 1 x power on/off button with LED (default ATX)
- AT/ATX mode through BIOS setting
|
| Shock |
- IEC 60068-2-27 2008 (with SSD: 50G, half-sine, 11 ms duration)
- MIL-STD-810H, Method 516.8, and Procedure I
|
| Construction |
- IEC 60068-2-64 2019 (with SSD: 3Grms, random, 5 to 500 Hz)
- MIL-STD-810H, Method 514.8, Category 20
|
| Vibration |
- Aluminum extrusion heavy-duty cold-rolled steel
|
| Operating Temperature |
- -40°C to +60°C with 14th/13th/12th gen Intel® Core™ processor and industrial wide temperature SSD, 0.7 m/s air flow
|
| IP Rating |
|
| Relative Humidity |
- 10% to 90% relative humidity, non-condensing
|
| Dimensions<br>(W x H x D) |
- 255 x 230 x 86.5 mm (10.04" x 9.06" x 3.41")
|
| Weight (net/gross) |
- 4.8 kg (10.58 lb)/6.3 kg (13.89 lb)
|
| EOS Support |
|
| Software Support |
- Windows® 10, Windows® 11, Windows® 10 IoT, Windows® 11 IoT, and Linux OS
|
| Certifications |
- CE (EN 61000-6-4/EN 61000-6-2), FCC
|
