| CPU |
- Intel® Core™ Ultra 7 processor 155H (16 cores, 28W TDP)
- Intel® Core™ Ultra 5 processor 125H (14 cores, 28W TDP)
- Intel® Core™ Ultra 7 processor 255H (16 cores, 28W TDP)
- Intel® Core™ Ultra 5 processor 225H (14 cores, 28W TDP)
|
| Chipset |
|
| System Memory |
- 2 x 262-pin DDR5 5600 MHz SO-DIMM, non-ECC, up to 96GB
|
| BIOS |
|
| COM |
- 2 x RS-232/422/485 with auto flow control
- 2 x RS-232 with auto flow control
|
| USB |
- 4 x USB 3.2 Gen2 (Type-A)
- 2 x USB 2.0 (Type-A)
- 1 x Type-C (USB 3.2 Gen 2, DisplayPort support)
- 1 x Type-C (USB 3.2 Gen 2, DisplayPort with 30W power delivery support)
|
| Ethernet/PoE |
- 3 x 2.5GbE (Intel® I226-IT)
- 1 x 1GbE (Intel® I210-IT)
|
| Display |
- 1 x HDMI 1.4b (lockable)
- 1 x DisplayPort 1.4a
|
| Digital I/O |
- 1 x 8-CH TTL DIO with DB9 female connector (4-in/4-out)
|
| Audio |
|
| Storage |
- 2 x 2.5" swappable SSD/HDD drive bay (up to 9.5 mm height & RAID 0, 1)
- 1 x M.2 2280 key M socket (PCIe Gen 4 x4)
|
| Expansion |
- 1 x full-size PCI Express Mini Card (USB + PCIe signal)
- 1 x M.2 Key E 2230 slot for Wi-Fi (USB 2.0 + PCIe signal)
|
| Others |
- TPM 2.0
- 1 x ATX power switch
- 1 x Remote power switch
- 1 x Reset switch connector
- 1 x Front-access SIM slot
- 4 x Antenna opening
|
| Power |
- 9 to 60 VDC
- 1 x Phoenix-type VDC power input connector
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Construction |
- Aluminum extrusion and heavy-duty steel
- IP40 with connector cables installed
|
| Operating Temperature |
- -40°C to +60°C (-40°F to +140°F) with 0.7 m/s airflow (with W.T. DRAM and SSD)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Vibration |
- IEC 60068-2-64 2019 (with SSD: 3Grm STD, random, 5 to 500 Hz, and 0.5 hr/axis )
- MIL-STD-810H, Method 514.8, Category 20, and Figure 514.8C-2
|
| Shock |
- IEC 60068-2-27 2008 Table A.1 (with SSD: 50G, half-sine, and 11 ms duration)
- MIL-STD-810H, Method 516.8, and Procedure I (with SSD: 40G, TP sawtooth, and 11 ms duration)
|
Dimensions
(W x D x H) |
- 250 x 170 x 60 mm (9.84" x 6.69" x 2.36")
|
| Weight (net/gross) |
- 2.4 kg (5.29 lbs)/3.2 kg (7 lbs)
|
| Certifications |
|
| EOS Support |
|
| Software Support |
|
| Mounting |
- Wall mount kit
- DIN-rail kit
|
