GOT817-834

Status : Available

17" SXGA TFT IP66 & IP69K-rated Stainless Steel Fanless PCT (or Resistive Touch) Panel Computer with Intel Atom® Processor E3827 and Flat Bezel Design (-20°C to +55°C)

Datasheet
Datasheet (PDF)
Add to Compare
Add to Compare
Get a Quote
Get a Quote
GOT817-834
GOT817-834
GOT817-834
GOT817-834
Fanless

Fanless

IP66 & IP69

IP66 & IP69

Low Power

Low Power

M12 Connector

M12 Connector

Wide Temperature

Wide Temperature

  • Features
  • Specifications
  • Ordering Information
  • Download
  • FAQ

Features

  • 17" SXGA TFT LCD flat bezel projected capacitive (or resistive) touch
  • IP66/IP69K-rated (NEMA 4X) water/dust/corrosion-proof design
  • Full stainless steel enclosure with type 316
  • -20°C to +55°C wide operating temperature range
  • Fanless system with Intel Atom® processor E3827
  • Optional Wi-Fi/3G kit for wireless network connectivity
  • 12 to 36 VDC wide range power input
  • M12 type I/O connectors for harsh environments

Specifications

LCD Panel
  • 17" SXGA TFT LCD
  • 350 nits
  • 1280 x 1024 pixels
CPU
  • Intel® Atom® processor E3827 1.75 GHz (Bay Trail)
Chipset
  • SoC integrated
System Memory
  • 1 x 204-pin DDR3L-1333 SO-DIMM dual channel, up to 8GB
BIOS
  • AMI
COM
  • 2 x RS-232/422/485 (default RS-232, A-Coded)
USB
  • 4 x USB 2.0 (A-Coded)
Ethernet
  • 1 x 10/100/1000 Mbps (X-Coded)
Display
  • N/A
Audio
  • N/A
Storage
  • 1 x 2.5" SSD
  • 1 x CFast™
Expansion
  • 2 x PCI Express Mini Card slot
Others
  • Waterproof, dustproof ventilation valve
  • 1 x DC power connector (M12)
Touchscreen
  • 5-wire resistive touch or projected capacitive multi-touch
Enclosure
  • Stainless type 316
Power Supply
  • 12 to 36 VDC
Power Comsumption
  • 50W
Watchdog Timer
  • 255 levels, 1 to 255 sec.
Operating Temperature
  • -20°C to +55°C (-4°F to +131°F)
Relative Humidity
  • 10% - 95% @ +40°C, non-condensing
Vibration
  • 2G, 5 - 500Hz, random for 2.5" SSD
  • 2G, 5 - 500Hz, random for CFast™
Dimensions (W x D x H)
  • 415.92 x 54.96 x 348.34 mm (16.37” x 2.16” x 13.71”)
Weight (net/gross)
  • 7.04 kg (15.52 lb)/ 10.3 kg (22.71 lb)
Certifications
  • CE
EOS
  • Windows® 10 IoT, Windows® 10, Windows® 8/8.1, WE8S, Windows® 7, WES 7
Mounting
  • Suspension
  • VESA mount

Ordering Information

  • GOT817-834-C-RF-DC (P/N-E22B817102)
    17" SXGA IP66 & IP69K-rated stainless steel fanless touch panel computer with Intel Atom® E3827, projected capacitive touch screen, flat-bezel design, and 12 to 36 VDC power input, supports WiFi
  • GOT817-834-R-RF-DC (P/N-E22B817100)
    17" SXGA IP66 & IP69K-rated stainless steel fanless touch panel computer with Intel Atom® E3827, 5-wire flat resistive touch screen, flat-bezel design, and 12 to 36 VDC power input, supports WiFi
  • 594B8122100E
    Water-proof COM cable (1.8 m)
  • 594B8122820E
    Water-proof USB cable (1.8 m)
  • 594B8152710E
    Water-proof LAN cable (1.8 m)
  • 509000002200
    Adapter 24V 90W, M12 A-code 5P

Download

Drivers

Date Description Version Download File
2017/07/24 Win8.x driver VA1.0
2017/07/24 Win7 driver VA1.0

Software

Manual

Date Description Version Download File
2017/07/24 GOT817-834 User's Manual VA1_11-30-2015 VA1.0
